01
Consultation & Layout
We confirm your layout, finishes and electrical standard, then lock the specification in CAD before production starts.
Day 0
[ Z-FOLD / RAPID DEPLOY / RELIEF ]
Rapid Z-Fold Container House
Efficient folding logic for fast modular deployment — a Z-shaped sequence that opens into a finished, wind-resistant space.
10
units
Per 40HQ
10
grade
Wind Rating
6–8
hrs
Install Time
12
kW
CE Electrical
[OVERVIEW]
Rapid Z-Fold Container House
The Rapid Z-Fold Container House adopts a Z-shaped folding sequence that allows the structural sections to open into a complete modular space. It is designed for projects that value quick deployment, compact transportation and repeatable factory-prefabricated construction.
[KEY FEATURES] Why Specifiers
Why Specifiers
Choose It.
- Z-Fold Mechanism — Single coordinated opening sequence with fixed wall panels — faster to close again for relocation.
- Fast Deployment — Unfold, level and connect in 6–8 hours with a 4–5 person crew.
- Repeatable Production — Identical units from one production jig keep multi-batch programs consistent.
- Wind-Resistant Frame — Grade 10 (265 km/h) engineering with anchoring details provided.
- Expandable Project Scale — Start with one container of ten units; scale to full camps in later batches.
[LAYOUT OPTIONS] Configure It
Configure It
Your Way.
Every layout ships with the agreed electrical standard, insulation package and interior finish — confirmed in CAD before production.
- Dormitory layout
- Site office
- Relief shelter layout
- Ablution or storage layout
- Customized project layout
[GALLERY] How the Z-Fold
How the Z-Fold
Opens.
From folded transport state to finished interior — the four key stages of the Z-fold sequence.
[TECHNICAL BRIEF]
Specifications.
Dimensions & Weight
- Folded dimensions
- Confirmed per order — drawing pack provided
- Expanded dimensions
- Confirmed per order — drawing pack provided
- Expanded floor area
- Confirmed per order — drawing pack provided
- Net weight
- Confirmed per order — drawing pack provided
Structure
- Folding mechanism
- Z-shaped folding structure, factory-integrated
- Main frame
- Galvanized steel structural frame
- Wall panels
- Insulated sandwich wall panels
- Roof / floor
- Insulated roof structure; structural floor with finished flooring
Performance
- Wind resistance
- Grade 10 (265 km/h)
- Electrical
- CE certified, 12 kW max, 63A RCD + MCB, copper wiring
- Water / drainage
- DN20 supply, DN50 drainage interface
Installation & Shipping
- Installation time
- 6–8 hours
- Installation team
- 4–5 persons
- Loading quantity
- 10 units / 40HQ
- Offloading
- Forklift or crane, min. 5 t
[SCOPE OF SUPPLY]
Standard Configuration
Standard supply scope for this model — the final package is confirmed line by line in your quotation.
| Category | Specification |
|---|---|
| Main Structure | Galvanized steel structural frame |
| Folding System | Factory-integrated folding mechanism, hinges, locking parts and support components |
| Wall System | Insulated sandwich wall panels |
| Roof System | Insulated roof structure with sealed waterproof joints |
| Floor System | Structural floor system with selected finished flooring |
| Doors | Steel entrance door |
| Windows | Aluminum alloy windows with glass |
| Electrical System | Lighting, switches, sockets, distribution box and internal wiring to the agreed standard |
| Plumbing System | Water supply and drainage pipelines where required by the confirmed layout |
| Installation Components | Locks, fasteners, sealing parts and required connection hardware |
[OPTIONS]
Optional Configuration
Select options according to climate, local standards and the final project layout.
| Category | Specification |
|---|---|
| Exterior Finish | Decorative wall cladding, wood-grain panels and customized exterior colors |
| Insulation | Rock wool, PU insulation or an upgraded thermal insulation package |
| Doors and Windows | Double glazing, insect screens, sliding doors, security doors and customized sizes |
| Interior Flooring | SPC, PVC, laminate or other project-specified flooring |
| Bathroom Upgrade | Water heater, mirror cabinet, upgraded sanitary ware and accessories |
| Electrical System | EU, US, UK, AU or other project-specific electrical standards |
| HVAC and Ventilation | Air conditioner, ventilation system and exhaust fans |
| Renewable Energy | Solar panels, inverter, battery storage and associated power components |
| Outdoor Accessories | Terrace, staircase, canopy, handrails and outdoor lighting |
| Furniture Package | Beds, wardrobes, sofa, dining furniture or office furniture |
| Smart and Safety Options | Smart door lock, access control, CCTV, smoke detector and project-specified safety devices |
[ COMPLIANCE ]
Engineered for Local Standards
CE-certified 12kW electrical systems with RCD + MCB protection ship as standard across the range. EU, US, UK and AU wiring packages, rock wool and PU insulation upgrades are available for compliance-driven projects. Component certificates (WaterMark-listed sanitary ware, tempered safety glass and more) are documented on our compliance page.
[ PROCESS ] From Order to
From Order to
Move-In Ready
A flat-packed SunModu unit follows a short, predictable path from confirmed layout to on-site installation — no wet trades, no long tails.
02
Factory Production
Steel framing, panels, interior fit-out, MEP and QC run through our own line — standard models in 15–20 days.
15–20 days
03
Flat-Pack & Containerize
Units are folded, protected and lashed into 40HQ containers with corner guards and film wrapping.
40HQ loading
04
On-Site Installation
A small crew unfolds, levels and connects the unit with basic tools — no crane on most sites.
Hours, not weeks
[FAQ] Common
Common
Questions.
How does Z-fold differ from mid-fold?
The Z-fold opens in a single coordinated sequence with fixed wall panels — faster to close up again for relocation. Mid-fold packs flatter for maximum container loading. Choose Z-fold for repeat deployment, mid-fold for lowest freight per unit.
How many units fit per container?
Ten units per 40HQ, flat-packed in the folded state with protective wrapping.
Is it suitable for high-wind sites?
Engineered to wind resistance Grade 10 (265 km/h) per the specification table; anchoring details are provided with the drawing pack.
What is the lead time?
Lead time is confirmed per order and volume with your quotation.
